Hardware Installation and Reference Guide
Status LED
Power Supply
Overall Power
Consumption
Bluetooth
Environment
Mounting Mode
IP Rating
Safety Regulation
Compliance
EMC Certification
Health Standard
Radio
Regulations
Caution
The weight indicates the total weight of the AP and mounting
Product Appearance
The RG-AP820(AR) provides three RF ports and three Ethernet ports. LAN 1/LAN 2 port can be used as an
uplink 1 Gbps copper port. LAN 1 port supports PoE/802.3at/802.3af power supply. LAN 3/IoT port can be
connected to Ruijie's IoT module for power supply (12 V/0.25 A, MAX: 2 W). In addition, there are one console
port, one power socket for an external power adapter, one USB port, and one reset hole. The following figures
show the appearance of the RG-AP820(AR).
One LED (It supports red, green, blue, orange, and blinking mode, blinks when
an STA is connected, and can be muted.)
Local power supply: DC 48 V/0.6 A (Note: The power adapter needs to be
purchased separately.)
PoE+, supporting IEEE 802.3af power supply and compatible with 802.3at power
supply
< 20 W
Bluetooth 5.0, supporting Apple iBeacon protocol, applicable to various Bluetooth
applications, such as shake and Bluetooth positioning applications
Operating temperature: –10° C to +50° C (14° F to 122° F)
Storage temperature: –40° C to +70° C (–40° F to +158° F)
Operating humidity: 5% to 95% (non-condensing)
Storage humidity: 5% to 95% (non-condensing)
Ceiling/wall-mountable
IP41
GB4943.1, EN/IEC 60950-1
GB9254.1, EN301 489
EN 62311
Radio Transmission Equipment Type Approval, EN300 328, and EN301 893
bracket.
3
Product Introduction
