Features of fiber transmission modules

MULTIMODE TRANSMISSION MODULE
Data transmission Type:
Type of interface:
Cable length (max.) Multimode 62.5/125 μm,
Class OM1:
Multimode 50.0/125 μm,
Class OM2:
Multimode 50.0/125 μm,
Class OM3:
Performance data Wavelength(λ):
Optical power output (P
in 50 oder 62,5 μm MMF:
Receiving sensitivity (P
Sensitivity – Stressed (P
SINGLEMODE (S) TRANSMISSION MODULE
Data transmission Type:
Type of interface:
Cable length (max.)
Singlemode 9/125μm,
Class OS1:
Performance data Wavelength(λ):
Optical power output (P
in 9 μm SMF:
Receiving sensitivity (P
SINGLEMODE (S+) TRANSMISSION MODULE
Data transmission
Type:
Type of interface:
Cable length (max.) Singlemode 9/125μm,
Class OS1:
Performance data
Wavelength(λ):
Optical power output (P
in 9 μm SMF:
Receiving sensitivity (P
Optical fibres (2 fibres)
LC duplex
100 meters
200 meters
400 meters
850 nm (830 nm bis 860 nm)
) -9,0 dBm bis -2,5 dBm
OUT
): -15 dBm (OMA)
MIN
138μW (50 μm MMF)
):
S
Optical fibres (2 fibres)
LC duplex
5 Kilometer
1310 nm (1260 nm bis 1350 nm)
) -9,5 dBm bis -3,0 dBm
OUT
): -18 dBm (OMA)
MIN
Optical fibres (2 fibres)
LC duplex
10 Kilometer
1310 nm (1260 nm bis 1360 nm)
) -8,4 dBm bis -1,0 dBm
OUT
): -18 dBm (OMA)
MIN
