Installing and connecting computer modules

Connecting computers to computer modules

IMPORTANT: The
Fiber
laser technology which comply with laser class 1.
They meet the requirements in accordance to
U.S. CFR 1040.10 and 1040.11
Mind the following instructions when dealing with laser beams:
 Avoid direct eye exposure to beam on page 4
 Always connect optical connections or cover them with protection caps on page 4
 Only use G&D certified transmission modules on page 4
NOTE:
The installation of the modules is described in detail in the separate manual
Computer modules and console modules
 Connect the computer to the different computer modules.

Connecting computer modules to the central module

IMPORTANT: Mind the following instructions when installing central modules
with fiber ports:
 Avoid direct eye exposure to beam on page 4
 Always connect optical connections or cover them with protection caps on page 4
 Only use G&D certified transmission modules on page 4
 Connect the Trans. interfaces of each individual computer module to one of the
Dynamic Ports of the central module.
2 4 6 8
Tx Rx Tx Rx Tx Rx Tx Rx
Rx 1 Tx Rx 3 Tx Rx 5 Tx Rx 7 Tx
IMPORTANT:
UC variants of computer modules provide two Trans. interfaces to
connect a computer to two different KVM matrix systems. Connect only one of the
computer module's Trans. interfaces to this matrix switch!
variants of the computer modules use components with
.
.
Dynamic Ports
10 12 14 16 18
Tx Rx Tx Rx Tx Rx Tx Rx
Rx 9 Tx Rx 11 Tx Rx 13 Tx Rx 15 Tx 17
EN 60825-1:2014 as well as
20 22 26
24
19 21 23 25
G&D ControlCenter-Compact · 9
Installation
28 30 32
27 29 31
