Status displays

LEDs at the front panel
The LEDs on the front panel of the matrix switch show the system's operating status:
Section LED
Power Red.
Main
Device Port-
function
Status
Fail
Ident.
Status Meaning
on The power pack is turned on and supplies the required
voltage.
off The power pack is turned off or the connection to the mains
could not be established.
on The power pack is turned on and supplies the required
voltage.
off The power pack is turned off or the connection to the mains
could not be established.
off The status is shown at the dynamic ports.
on The port mode is shown at the dynamic ports.
blinking The central module is ready for operation.
on The central module is being initialised.
on The device is not ready for operation.
off The device is ready for operation or turned off.
on The LED to identify the device in the web application is
activated.
off The LED to identify the device in the web application is
deactivated.
