Expanding switchable signals

Expanding switchable signals
You can expand a computer's or a console's switchable signals through channel
grouping.
EXAMPLE: To transmit a second video signal and a USB 2.0 signal of the same
computer, in addition to the
module (second video channel) and a
computer.
In addition to the
video channel) and a
aforementioned computer is accessing.
The web application lets you assign up to seven additional video channels and one
USB 2.0 or RS 232 channel to the KVM channel of the console.
You can assign up to seven additional video channels to the KVM channel of the com-
puter, too. In addition, you can create a
channel.
NOTE:
Within the channel groups of the console a USB 2.0/RS 232 channel or a
multi-channel represent one single device. For computers such a channel repre-
sents a group of up to four devices.
By using pools, you can grant up to four users the right to access the USB 2.0/
RS 232 channel at the same time. For this, the matrix switch selects an available device
from the pool after switching.
Assigning multiple channels to a console or computer creates a channel group.
NOTE: The OSD does not show any console or computer modules that you added
as additional channels to the channel group.
Detailed information on channel grouping can be retrieved in the web application
manual.
20 · G&D ControlCenter-Compact
DVI-CPU computer module, connect a second
DVI-CON console module, connect the
U2+R-CON module (USB2.0/RS232) to the console, the
U2+R-CPU module (USB2.0/RS232) to the
of four devices for the USB 2.0/RS 232
pool
DVI-CPU
DVI-CON-Video (second
