Applying a LUT to Video Outputs
• Repeat steps 1 and 2 as necessary to apply LUTs to other video outputs with the following settings:
[LUT: SDI OUT] and [LUT Selection: SDI OUT]: video output from the SDI OUT terminal,
[LUT: MON.] and [LUT Selection: MON.]: external monitor connected to the MON. terminal,
[LUT: HDMI] and [LUT Selection: HDMI]: external monitor connected to the HDMI OUT terminal,
158
[LUT: EVF-V50] and [LUT Selection: EVF-V50]: optional viewfinder.
List of LUTs
Applied LUT
[BT.709]
[BT.2020]
[DCI]
[PQ]
[HLG]
[ACESproxy]
[CMT 709]
[HDR Assist. (1600%)]
[HDR Assist. (400%)]
NOTES
• When you apply the [ACESproxy] LUT to the SDI OUT terminal, MON. terminal or HDMI OUT terminal, the
terminal will output ACESproxy video data. Using a compatible monitor, you can perform on-set color grading
and check the image after color correction as you continue shooting (A 23).
• If you set an assignable button to [LUT: All], [LUT: VIDEO Term.], [LUT: EVF-V50], [LUT: SDI OUT], [LUT: MON.]
or [LUT: HDMI] (A 125), you can press the button to turn the selected LUT on and off on all monitoring
devices, the supplied LCD screen, an optional viewfinder or external monitors, respectively.

Adjusting the Color Quality for HLG Output

You can change the quality of the color reproduction when the [HLG] LUT is used.
Select > [¢ Monitoring Setup] > [HLG Color] > Desired option.
Options
[BT.2100]: Color reproduction according to ITU-R BT.2100 specifications.
Output Settings
with LUT applied
Gamma curve Color space
BT.709
BT.709
Wide DR
BT.709
BT.2020
Wide DR
DCI DCI-P3
PQ BT.2020
HLG BT.2020
ACESproxy ACESproxy
CMT 709 BT. 709
Original
BT.709
gamma curve
LUT for viewing on the LCD screen and external monitors compatible with BT.709
specifications.
LUT for viewing on external monitors compatible with ITU-R BT.2020 standards,
which define parameters for ultra-high-definition television (4K/8K).
LUT for viewing on external monitors that support color spaces and gamma
curves that follow the guidelines established by DCI (Digital Cinema Initiatives).
LUT for viewing HDR (high dynamic range) images on external monitors
compatible with the PQ standard defined by ITU-R BT.2100. The signal output will
use narrow range (video range) coding.
LUT for viewing HDR (high dynamic range) images on external monitors
compatible with the HLG standard defined by ITU-R BT.2100. The signal output
will use narrow range (video range) coding.
LUT for viewing on external monitors compatible with the ACESproxy standard
established by ACES (Academy Color Encoding System). The signal output will use
narrow range (video range) coding.
LUT for viewing on the LCD screen and external monitors compatible with BT.709
specifications. It produces a look suitable for a cinema production, keeping a wide
dynamic range without clipping when log recording.
LUT for viewing HDR (high dynamic range) images on LCD screens and optional
viewfinders connected to the VIDEO terminal or to an optional viewfinder attached
to the system expansion terminal. The LUT follows the ITU-R BT.2100 transfer
function to convert a brightness range of 1600% or 400% respectively into a
linear brightness scale.
Description
