GVM -PRO-SD300C Manual page 12

FUNCTIONS INTRODUCTION &
INSTRUCTIONS
① MENU:
Press the [MENU] button to enter the menu setting page. Rotate [Knob 1] to select a sub
menu. Press [Knob 1] to enter the corresponding menu interface. The menu setting
interface includes output modes, DMX settings, DIM curve, WL settings, studio,
frequency settings, fan settings, language, and system settings.
OUTPUT MODES: You can go through the output
mode by rotating [Knob 1]. Short press [Knob 1] to
select and enter the setting page, from here you can
set the light to either [Wide CCT(2000K~10000K)] or
[Finely CCT(2700K~6800K)] output mode. This
setting is only available in CCT mode.
DMX SETTINGS: Rotate [Knob 1] to select the
corresponding parameters, press [Knob 1] to adjust
parameters, set DMX parameters, set [Address (001-
512)] and accuracy [(8bit/16bit)], and 9 DMX modes:
CCT & RGB, CCT & HSI, CCT, RGB, HSI, SOURCE,
GEL, FX, Ultimate.
DIM CURVE: Rotate [Knob 1] to select the dimming
curve, you can choose [Linear / Logarithmic /
Exponential / S Curve].
WL SETTINGS: Rotate [Knob 1] to select the
parameter to be adjusted, RF channel settings, RF
switch, Bluetooth switch, and Bluetooth reset can be
performed in this page.
STUDIO: Turn on and off studio mode.
Studio ON: The light will remember its current
settings. Upon restarting the light it will
automatically bring up the previous saved settings.
Studio OFF: The light will set back to its default
factory settings upon restarting the light.
10
