DESCRIPTION OF PRODUCT
CONTROL BUTTONS
1
Display screen: Display current settings, modes and parameters.
2
Mode button: Light mode switch button.
3 Menu button: Press this button to enter the menu setting page.
4
Back button: Press this button to return back to the previous menu page.
5
Cooling button: Start a large air volume cooling until the temperature is reduced
to a touchable temperature.
6
Knob 1: INT/SELECTOR multi-functional knob, by pressing or rotating it can be
used to select or adjust brightness ouput.
7
Knob 2: Parameter adjustment knob, adjust CCT, HUE, SAT, R，G，B, SPD, and
Green and Magenta Shift parameters.
8
Power ON/OFF button.
1
OFF
8
ON
DC IN
4 5
2 3
MODE MENU BACK COOL
6 7
INT/SELECTOR CCT/GM
PUSH
DMX IN DMX OUT
9
