Appendix A
The Mobileye Shield+ system should function normally by considering vehicle's movement and angle
changes according to driving path.
Installation process of each of the cameras in an articulated vehicle is identical to a standard shield+
installation with a few remarks as below.

9.1 Guidelines for articulated Shield+ installation

• Cables length and extensions - In order not to exceed the CAN network length (which is
approximately 100m), cable length adjustment should be in a proper way.
• Termination resistors – it will probably be required to use one or two termination resistors
(120Ω or 60Ω) and connect it between CAN high & CAN low wires of CAB000165.
• Display units - the sides display unit will cover each side regardless of how many cameras are
connected, therefore, there is no need for an additional sides display.
• JB connection – when installing a trailer that can be separated from the main cabin, we are
using a retractable Suzi cable to connect between the junction box located in the trailer to
the Junction box located in the main cabin.
• External waterproof box – when installing the JB or the bridge unit outside the vehicle
(usually at the bottom of the vehicle), we will use an external waterproof box which comply
with standard IP67. Also, possible to use Mobileye waterproof box (ITM000656).
• Retractable Suzi cable – physical design according to standard ISO 7638-1 / 7638-2 to allow
CAN-bus communication. (Does not provided by Mobileye).
