8.2 System Status

Mobileye Shield+ V2.0 system has a status indication via the Eyewatch display unit.
This will indicate the driver if any error or visibility issue exist with the rear camera.
System Status
No Errors – system is fully
working
Error in System
Low visibility on rear camera –
VRU won't be detected
Night mode –
system is not detecting VRU's
Status indication is available on Mobileye 6 series with firmware version 2.7.
The new icons are available ONLY on EyeWtach3 equipped with the latest EyeWatch FW
version.
The EyeWatch3 FW version cannot be upgraded on site.

8.3 Front camera functionality

Testing the front camera will be performed as instructed in the standard Mobileye 6 installation manual.
Please use extra caution when performing the test.
Mobileye does not recommend testing FCW due to safety issues.
Mobileye Shield+ V2.0| January 2022
Installation Manual v1.1
Icon on EW3
Constant
Blinking
Mobileye Proprietary and Confidential
support@mobileye.com
MOBILEYE, AN INTEL COMPANY
WWW.MOBILEYE.COM
Possible Solution
N/A
Contact Mobileye technical support
team
Check rear camera's view – if needed,
clean lens
Expected behavior – no action required
