Drivers should exercise caution in using the Mobileye Shield+ Display unit. Always maintain full
concentration on the road including while looking at the Mobileye Shield+ display unit.
The Mobileye Shield+ is intended for paved roads, with clear lane markings.
The Mobileye Shield+ detects only fully visible pedestrians and cyclists (Day only).
The Mobileye Shield+ does not guarantee 100% accuracy in the detection of pedestrians and
cyclists, nor in providing warnings of all potential road hazards. In addition, road, weather, and
other conditions can adversely affect the Mobileye Shield+ system's recognition and response
capabilities.
Any conditions that form partial or full blockage of the camera's view will result in reduced or
non-functionality of Mobileye Shield+ performance. Always ensure clear camera view.
The information and illustration images in this document are an example only and do not limit
the installation to a specific vehicle type.
The use of bus in this document is for ease of illustrating only!
1.2 Installation and Safety Instructions
Mobileye Shield+ installation must be carried out by an Authorized Mobileye Dealer or Installer.
The Mobileye Shield+ should only be operated with 12VDC~24VDC power.
Do not cover or obstruct the Camera Unit or Mobileye Shield+ Display and Control Unit.
Only proper tools are to be used.
Only L.E.D voltage tester or Digital Multi Meter should be used.
The use of light bulb voltage tester is prohibited.
Pay attention to unusual color cables for example: yellow cable isolation belongs to air bags; two
twisted wires usually belong to different sensors (digital).
Before disconnecting the battery or the radio connectors make sure to have the radio code.
Do not disconnect any plug or connector in the vehicle when the ignition switch is turned on.
Mobileye Shield+ V2.0| January 2022
Installation Manual v1.1
Mobileye Proprietary and Confidential
