Installation -
Cabling
Pass the wires through and make all necessary connections.
Use a PoE Injector (required. Sold separately)
to connect data and power to the camera
using a single Ethernet cable.
Power requirements
DC12V, PoE IEEE 802.3af
Class2 (Adapter not included)
Use non-PoE Switch to connect data using and
Ethernet cable and use a power adapter to
power the camera.
OR
Power consumption
1A adapter is recommended
DC12V Max 4W, PoE Max 4.8W
