Installation -

Cabling

Pass the wires through and make all necessary connections.
Use a PoE Injector (required. Sold
separately) to connect data and power to
the camera using a single Ethernet cable.
Power requirements
DC12V, PoE (IEEE 802.3af class 3).
Adapter not Included.
Use a non-PoE Switch to connect data
using an Ethernet cable and use a power
adapter to power the camera.
OR
Power consumption
12V DC: 10.2W, 850mA
PoE: 12.5W, 260mA
