Installation -
Cabling
Pass the wires through and make all necessary connections.
Use a PoE Injector (required. Sold
separately) to connect data and power to
the camera using a single Ethernet cable.
Power information
Power requirements
Power consumption
Maximum cable distance
Connector
OR
DC12V, PoE IEEE 802.3af Class 3 (Adapter not included)
12V DC: 8.8W, 733.3mA,PoE: 11.1W, 231.25mA
328' (100m)
RJ45
11
11
Use a non-PoE Switch to connect data
using an Ethernet cable and use a power
adapter to power the camera.
