1
RFL-C series continuous fiber laser
Power indicator, including 100, 200L, 200, 300L, 300, 500, 750, 1000, 1500,
2
2000 respectively representing 100W, 170W, 200W, 250W, 300W, 500W,
750W, 1000W, 1500W, 2000W power laser
3 Wavelength, 'B' represents a wavelength of 1080nm
Output cable length, unit meter, including 10 meters and 20 meters, also can
4
be customized length
5 Cooling method, 'W' stands for water cooling, 'A' stands for air cooling
Notes: RFL-C100 ~ RFL-C3000 laser without air conditioning

2.3 Package accessoriesare

Please refer to package accessoriesare in the packing box.

2.4 Unpacking and Inspection

Raycus fiber laser is delivered in a package, which is designed to offer the
maximal safety. Upon the delivery, please inspect all packaging for evidence of
mishandling or damage. If you find any evidence of mishandling, please keep the
damaged material and contact the shipping agent and Raycus immediately.
Please double check if each listed contents is inside the package; and contact
Raycus as soon as possible if there is any issue.
Take extra care when removing the unit from the package to make the fiber
optic cable stay away from collision and vibration. Please do NOT distort, bend or
pull the output cable when unpacking the device; and avoid any collision to the
head of laser output.
 CAUTION: The fiber optic cable and output head
are precise optic instrument, ANY vibration or impact to the
output head, and twist or excessive bend to the cable will
damage the instrument.

2.5 Operation Environment

The operation conditions are listed as the following table:
Wuhan Raycus Fiber Laser Technologies Co., Ltd
User Guide of Global Version 2000 W CW laser
Raycus User Guide | Product Description
8
5
