pArtS NEEdEd
5 or 6 AF-2- Crossmember-
Above - Place the top corner of the A-FRAME CROSS-
MEMBER to the outside of the A-FRAME LEG. Use a
clamp or another person to hold one side while leveling.
Once level and held down, use a 1/2" bolt of any size
longer then 5" and a blunt object to mark a hole on the A-
FRAME LEGS.
SWING BEAM INStAll
(1)
USB-4- 1/2" USS Flatwasher-
USB-8- 1/2" Hex Nut-
USB-14- 1/2" x 7" Carriage Bolt- (2)
HArdWArE NEEdEd
(2)
USB-6- 1/2" Split Lockwasher-
(2)
USB-10- 1/2" Acorn Nut Plated-
USB-3- 3/4" USS FLatwasher-
USB-10
USB-6
USB-8
USB-4
(2)
(2)
(2)
USB-3
USB-14
