SETUP FOR PROTONODE

2.1 Record Identification Data

Each ProtoNode has a unique part number located on the side or the back of the unit. This number
should be recorded, as it may be required for technical support. The numbers are as follows:
•
FPC-N34 units have the following 3 ports: RS-485 + Ethernet + RS-485
•
FPC-N35 units have the following 3 ports: LonWorks + Ethernet + RS-485

2.2 Point Count Capacity and Registers per Device

The total number of Registers presented by all of the devices attached to the ProtoNode
cannot exceed:
Model
ProtoNode N34
ProtoNode N35

Figure 1: ProtoNode Part Numbers

Part number
FPC-N34-0710
FPC-N35-0771

Figure 2: Supported Point Count Capacity

Devices
Envi
Love
Nuro

Figure 3: Registers per Device

Page 8 of 50
Part Number
FPC-N34-0710
FPC-N35-0771
Total Registers
1,500
1,500
Registers Per Device
53
40
64
ProtoNode Startup Guide
