Appendix B. Vendor Information

NOTE: All Modbus TCP/IP registers are the same as the Modbus RTU registers for the serial device. If this point list is needed, contact the OEM. The
Modbus TCP/IP node address of the device is also the same as the Modbus RTU node address.
Appendix B.1. ENVI Modbus RTU Mappings to BACnet, Metasys N2, Modbus TCP/IP and LonWorks
Point Name
State
Supply Temp
Return Temp
DHW Temp
Header Temp
Firing Rate
Flue Gas Temp
HX Temp
Outside Temp
Flame Signal
CH Setpoint
DHW Setpoint
Boiler Operation
High Outdoor Air Temp
Min Outdoor Air Setpoint
Low Outdoor Air Temp
Max Outdoor Air Setpoint
Outdoor Air Shutdown Temp
Night Setback
Error Code
Analog In
Analog Out
Ignitions
Burner High Hours
Burner Medium Hours
Burner Low Hours
BACnet BACnet N2
Object Object Data
Type ID Type
AI 1 AI
AI 2 AI
AI 3 AI
AI 4 AI
AI 5 AI
AI 6 AI
AI 7 AI
AI 8 AI
AI 9 AI
AI 10 AI
AV 11 AO
AV 12 AO
AV 13 AO
AV 14 AO
AV 15 AO
AV 16 AO
AV 17 AO
AV 18 AO
AV 19 AO
AI 20 AI
AI 21 AI
AI 22 AI
AI 23 AI
AI 24 AI
AI 25 AI
AI 26 AI
N2
Point
Lon Name
Address
1
nvoState_XXX
2 nvoSupplyTmp_XXX
3
nvoReturnTmp_XXX
4 nvoDHWTmp_XXX
5 nvoHeaderTmp_XXX
6 nvoFiringRat_XXX
7
nvoFluGasTmp_XXX
8 nvoHXTmp_XXX
9 nvoOutsidTmp_XXX
10 nvoFlameSig_XXX
11 nvi/nvoCHSP_XXX
12 nvi/nvoDHWSP_XXX
13
nvi/nvoBlrOpera_XXX
14 nvi/nvoHiOATmp_XXX
15 nvi/nvoMinOASP_XXX
16 nvi/nvoLoOATmp_XXX
17 nvi/nvoMaxOASP_XXX
18 nvi/nvoOAShtdnTp_XXX
19
nvi/nvoNightStbk_XXX
20 nvoErrorCode_XXX
21 nvoAnalogIn_XXX
22 nvoAnalogOut_XXX
23 nvoIgnitions_XXX
24 nvoBrnrHiHrs_XXX
25
nvoBrnrMdHrs_XXX
26 nvoBrnrLoHrs_XXX
Page 38 of 50
ProtoNode Startup Guide
Data Array
Lon SNVT
Name
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_lev_percent DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_count_inc_f DA_Byt_XXX
SNVT_volt DA_Byt_XXX
SNVT_volt DA_Byt_XXX
SNVT_count_inc_f DA_U16_XXX
SNVT_time_hour DA_U16_XXX
SNVT_time_hour DA_U16_XXX
SNVT_time_hour DA_U16_XXX
Offset
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
11
12
13
14
