Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
(-) Ground: Black or
Black/striped, pin 4
(+) Ignition: Pink or Pink/White, pin 3
(MUX) Ignition:
Violet/Brown, pin 1
1
Red/Striped,
(+) Parking light
Refer to the
"Vehicle connections" section
for wire and connector details.
6 403.CHRYSLER 7.36 2013 Chrysler 200
©2023 Directed. All rights
CAN B High: White/Orange, pin 6
Sentry Key Module
(black 8-pin conn.,
connector side view)
8
(+) 12V:
CAN B Low: White or White/Pink, pin 7
Red or
pin 5
87
87a
86 85
30
(+) 12V
Fuse 15A
(+) 12V Input
(-) Driver Door Trigger
CAN C High: pin 6
Diagnostic
1 8
Connector OBDII
(connector side view)
9 16
CAN C Low: Orange or
White/ Dk. Blue, pin 14
HS CAN 1 High: Tan/Black: 3
HS CAN 1 Low: Tan: 4
HS CAN 2 High: Orange/Green: 5
HS CAN 2 Low: Orange/Brown: 6
(+) 12V Input: Brown: 7
Ignition Output: Yellow: 8
(+) 12V Input: Red: 13
(-) Ground: Black: 14
(-) Parking Light Output: Green/Black: 2
(MUX) Ignition Output: Violet/Green: 8
(MUX) Ignition Output: Violet/Brown: 9
(-) RAP Off Output: Yellow/Black: 10
).
You can connect either a
SmartStart Pro, XL202, or Digital
RF Kit (requires version .101+).
Refer to the SmartStart/Digital RF
Kit/XL202 Installation Notes for
more information.
6: White/Black:
(-) Hood Input
Remote Start Safety
Override Switch
Hood Pin
