Vehicle connections

The connection information listed below is specific to the 2013 Chrysler 200. Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
8 403.CHRYSLER 7.36 2013 Chrysler 200
©2023 Directed. All rights
Description
No Connection
No Connection
(DATA) HS CAN 1 High
(DATA) HS CAN 1 Low
(DATA) HS CAN 2 High
(DATA) HS CAN 2 Low
Relay N.O. - 12 Volt Input
Relay COM. - Ignition Output
Relay N.C. - Ignition Interrupt
Relay N.C. - No Connection
Relay COM. - Starter OutputNo Connection
Relay N.O. - No Connection
(+) 12 Volt Input
(-) Ground
Description
No Connection
(-) Parking Light Output
No Connection
No Connection
No Connection
No Connection
No Connection
(MUX) Ignition Output
(MUX) Ignition Output
(-) RAP Off Ouput
No Connection
No Connection
Connects To
Wire Location
No Connection
No Connection
Sentry Key Module on ignition switch, black 8 pin plug, pin 6
Sentry Key Module on ignition switch, black 8 pin plug, pin 7
OBD-data link connector, black 16 pin plug, pin 6
OBD-data link connector, black 16 pin plug, pin 14
above driver kick, green 43 pin plug, pin 4
Sentry Key Module on ignition switch, black 8 pin plug, pin 3
No Connection
No Connection
No Connection
No Connection
above driver kick, green 43 pin plug, pin 4
Sentry Key Module on ignition switch, black 8 pin plug, pin 4
Connects To
Wire Location
No Connection
Must use a relay.
15A fuse to 12V.
driver kick, harness to rear
No Connection
No Connection
No Connection
No Connection
No Connection
Sentry Key Module on ignition switch, black 8 pin plug, pin 1
Sentry Key Module on ignition switch, black 8 pin plug, pin 1
under driver dash, lt. gray 43 pin plug, pin 14
No Connection
No Connection
(+/-) Wire Color
data white/orange (CAN B BUS)
data white (CAN B BUS)
data white/lt. blue (Diagnostic CAN
C)
data white/dk. blue (Diagnostic
CAN C)
+ red (40A)
+ pink
+ red (40A)
- Black
(+/-) Wire Color
+ white/violet
MUX violet/brown
MUX violet/brown
- violet
