Functions compatible with the 2013 Chrysler 200
3x LOCK START (Start control using OEM Remote)
3x LOCK STOP (Stop control using OEM Remote)
Arm Factory Security
Brake Status (foot brake)
Control of aftermarket alarm with OEM remote
Disarm Factory Security
Door Lock Control
Door Unlock
Driver Priority Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Fuel level/EV battery level
Ignition Status
Immobilizer Bypass-Data No Key Req'd
Parking Lights Control
RAP Shut Down (Retained ACC Power)
Remote Start Ready
Remote Start Takeover
SmartStart
Tach / RPM Output
Trunk / Hatch Release
403.CHRYSLER
v7.36
2013 Chrysler 200
CHTHD2, THCHD2 Compatible
(Sold Separately)
Advertisement
Table of Contents
Related Manuals for Directed Directechs DB3
Summary of Contents for Directed Directechs DB3
- Page 1 403.CHRYSLER v7.36 2013 Chrysler 200 CHTHD2, THCHD2 Compatible (Sold Separately) Functions compatible with the 2013 Chrysler 200 3x LOCK START (Start control using OEM Remote) Entry Monitoring Trunk/Hatch Pin 3x LOCK STOP (Stop control using OEM Remote) Fuel level/EV battery level Arm Factory Security Ignition Status Brake Status (foot brake)
-
Page 2: Table Of Contents
Contents Introduction Pre-installation and application warnings Installation Wiring diagram with T-Harness CHTHD2 (R1-R6 & R9-R10) or THCHD2 (R1) Wiring diagram Locating components in the vehicle Vehicle connections Module programming Key-type Vehicles Push-to-Start (PTS) Vehicles SmartStart Pro/Digital RF Kit/XL202 installation notes LED diagnostics and troubleshooting Parking light error codes Soft reset... -
Page 3: Introduction
• XL202 & Analog RF Kit Notes • This module can only be flashed and configured using DirectLink at www.directechs.com. • RSR mode is not compatible with vehicles equipped with a manual transmission. 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... -
Page 4: Pre-Installation And Application Warnings
Footnotes [1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if not supported in data. 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... -
Page 5: Wiring Diagram With T-Harness Chthd2 (R1-R6 & R9-R10) Or Thchd2 (R1)
Refer to the SmartStart/Digital RF Kit/XL202 Installation Notes for (-) Driver Door more information. Trigger (+) 12V Input Refer to the “Vehicle connections” section (+) Parking lights for wire and connector details. 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... -
Page 6: Wiring Diagram
Remote Start Safety Override Switch (+) 12V Fuse 15A Hood Pin (+) Parking light (+) 12V Input Refer to the “Vehicle connections” section (-) Driver Door Trigger for wire and connector details. 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... -
Page 7: Locating Components In The Vehicle
Locating components in the vehicle 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... -
Page 8: Vehicle Connections
Sentry Key Module on ignition switch, black 8 pin plug, pin 1 violet/brown H2/10 Yellow/Black (-) RAP Off Ouput under driver dash, lt. gray 43 pin plug, pin 14 violet H2/11 Orange/Black No Connection No Connection H2/12 Blue/Red No Connection No Connection 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... - Page 9 H4/1 Blue (Data) TX H4/2 Black (-) Ground H4/3 Green (Data) RX H4/4 (+) 12 Volt RF 2-pin white connector (H5) Module Conn./Pin Color Description H5/1 No Connection H5/2 No Connection 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights...
-
Page 10: Module Programming
Press Lock or Unlock on the factory transmitter. The LED will turn ON solid green OR orange for 3 seconds and then shut off. You have successfully completed the module programming sequence. 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... -
Page 11: Push-To-Start (Pts) Vehicles
Press Lock or Unlock on the factory transmitter. The LED will turns ON solid green OR orange for 3 seconds and then turn off. You have successfully completed the module programming sequence. 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... -
Page 12: Smartstart Pro/Digital Rf Kit/Xl202 Installation Notes
Use the D2D Crossover (XOVER) cable that is provided with XL202 (not the one in the DB3 package) Follow the XL202 Programming Guide to pair the remote to the XL202. XOVER Cable XOVER Cable Note: The XL202 and antenna are optional and must be purchased separately. 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... -
Page 13: Led Diagnostics And Troubleshooting
Flashes red x 7 External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... - Page 14 Lock Start is selected from the web in the flashing process. Flashes red x 7 Feature error. An RSR feature file mismatch was detected. Please contact Technical Support. Flashes red x 9 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights...
-
Page 15: Parking Light Error Codes
Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the & LED starts to flash orange and red. Solid Flashes Release the programming button. The LED turns ON solid red. & Solid Release 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... -
Page 16: Limited One Year Consumer Warranty
This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... -
Page 17: Quick Reference Guide (Customer Copy)
® ® ® Autostart and AstroStart models. Icons and commands may differ depending on the ® ® model and options purchased. Refer to your authorized installation center for more specific information. 403.CHRYSLER 7.36 2013 Chrysler 200 ©2023 Directed. All rights... - Page 18 * Press & hold for 5 seconds to activate the trunk release (optional). * Icon and remote appearance may differ depending on the model purchased. SmartStart compatible This system is compatible with Directed SmartStart. For a complete list of supported features, please visit www.mysmartstart.com. What is SmartStart? Now you can remote start, lock and unlock your car just by pushing a button on your mobile device;...
