0.40 [10.05]
0.86 [21.95]
6.09 [154.76]
7.90 [200.61]
0.55 [13.85]
Figure 5:
ECY-VAV Series Controllers with Terminal Covers Dimensions (Typical)
Configuration Jumper Location and Identification
Controllers have the following onsite configurable jumpers. Remove the ECY-VAV Series controller's cover to access these items.
Figure 6:
ECY-VAV Series Controller Jumper, Reset Button, and LED Indicator Locations.
4 / 16
10.84 [275.26]
5.42 [137.63]
Front
Jumpers for
DO3 & DO4
Jumpers for
DO1 & DO2
* Factory-default positions
Sliding Grommet
Cover Removed
POWER
RESET
STATUS
Digital Outputs (DO)
Power Source
Triac Internal
Triac External
Power*
Powered
FUSE
3.70 [94.04]
1.25 [31.75]
½-inch
knockout:
Ø 0.875 (7/8)
[Ø 22.23]
4 Positions
Profile
Inches [Millimeters]
±0.20
[± 5]
