17. Installing a communication interface module
DANGER
Electric shock
Death or serious personal injury
- Switch off the power supply to the motor and to the
signal relays. Wait at least 5 minutes before
starting any work on the motor. Make sure that the
power supply cannot be accidentally switched on.
Always use an antistatic service kit when handling
electronic components. This prevents static
electricity from damaging the components.
When unprotected, place the component on the
antistatic cloth.
Fig. 55 Antistatic service kit
1. Loosen the four screws (fig. 56, A) and remove the terminal
box cover (fig. 56, B).
A
B
Fig. 56 Removing the terminal box cover
2. Remove the CIM cover (fig. 57, A) by pressing the locking tab
(fig. 57, B) and lifting the end of the cover (fig. 57, C). Then lift
the cover off the hooks (fig. 57, D).
C
B
Fig. 57 Removing the CIM cover
52
D
A
3. Remove the securing screw (fig. 58, A).
A
Fig. 58 Removing the securing screw
4. Fit the CIM module by aligning it with the three plastic holders
(fig. 59, A) and the connecting plug (fig. 59, B). Press home
the module using your fingers.
A
Fig. 59 Fitting the CIM module
5. Fit and tighten the securing screw (fig. 58, A) to 1.3 Nm.
6. Make the electrical connections to the CIM module as
described in the instructions delivered with the module.
7. Connect the cable screens of the bus cables to ground (earth)
via one of the ground (earth) clamps (fig. 60, A).
Fig. 60 Connecting the cable screens to ground (earth)
B
A
