Appendix A - Parameters
9.3.3 5-** Digital In/Out
Par. Parameter description
No. #
5-0* Digital I/O mode
5-00 Digital I/O mode
5-01 Terminal 27 mode
5-02 Terminal 29 mode
5-1* Digital Inputs
5-10 Terminal 18 digital input
5-11 Terminal 19 digital input
5-12 Terminal 27 digital input
5-13 Terminal 29 digital input
5-16 Terminal X30/2 digital input
5-17 Terminal X30/3 digital input
5-18 Terminal X30/4 digital input
5-19 Terminal 37 Safe stop
5-3* Digital Outputs
5-30 Terminal 27 Digital output
5-31 Terminal 29 Digital output
5-4* Relays
5-40 Function relay
9 9
5-41 On delay, relay
5-42 Off delay, relay
9.3.4 8-** Comm. and Options
Par. Parameter description
No. #
8-0* General Settings
8-01 Control site
8-02 Control word source
8-03 Control word timeout time
8-04 Control word timeout function
8-05 End-of-timeout Function
8-06 Reset control word timeout
8-3* FC Port Settings
8-30 Protocol
8-31 Address
8-32 FC port baud rate
8-35 Minimum response delay
8-36 Max response delay
8-37 Max Iiter-char delay
8-5* Digital/Bus
8-53 Start select
8-55 Set-up select
106
®
VLT Refrigeration Drive FC 103 Low Harmonic Drive
Default value
[0] PNP
[0] Input
[0] Input
[8] Start
[0] No operation
[0] No operation
[0] No operation
[0] No operation
[0] No operation
[0] No operation
[1] Safe Stop Alarm
[0] No operation
[0] No operation
[0] No operation
0.30 s
0.30 s
Default value
[0] Digital and ctrl.word
null
1.0 s
[0] Off
[1] Resume set-up
[0] Do not reset
[1] FC MC
2 N/A
[2] 9600 Baud
10 ms
5000 ms
25 ms
[3] Logic OR
[3] Logic OR
Danfoss A/S © 08/2015 All rights reserved.
4-set-up Change Conver-
during sion index
operation
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
4-set-up Change Conver-
during sion index
operation
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
1 set-up TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
Type
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-2 Uint16
-2 Uint16
Type
- Uint8
- Uint8
-1 Uint32
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint8
- Uint8
-3 Uint16
-3 Uint16
-3 Uint16
- Uint8
- Uint8
