Commissioning
•
Restoring factory default settings does not
change data stored in the LCP memory.
5.3.4 Uploading/Downloading Data to/from
the LCP
1. Press [Off] to stop operation before uploading or
downloading data.
2. Press [Main Menu] parameter 0-50 LCP Copy and
press [OK].
3. Select [1] All to LCP to upload data to the LCP or
select [2] All from LCP to download data from the
LCP.
4. Press [OK]. A progress bar shows the uploading or
downloading progress.
5. Press [Hand On] or [Auto On] to return to normal
operation.

5.3.5 Changing Parameter Settings

Access and change parameter settings from the Quick
Menu or from the Main Menu. The Quick Menu only gives
access to a limited number of parameters.
1. Press [Quick Menu] or [Main Menu] on the LCP.
▲ ▼
2.
Press [ ] [ ] to browse through the parameter
groups, press [OK] to select a parameter group.
▲ ▼
3.
Press [ ] [ ] to browse through the parameters,
press [OK] to select a parameter.
▲ ▼
4.
Press [ ] [ ] to change the value of a parameter
setting.
5. Press [◄] [►] to shift digit when a decimal
parameter is in the editing state.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter Status, or press
[Main Menu] once to enter the Main Menu.
View changes
Quick Menu Q5 - Changes Made lists all parameters
changed from default settings.
•
The list only shows parameters, which are
changed in the current edit set-up.
•
Parameters, which were reset to default values,
are not listed.
•
The message Empty indicates that no parameters
are changed.
MG16N102
Operating Instructions

5.3.6 Restoring Default Settings

NOTICE
Risk of losing programming and monitoring records by
restoration of default settings. To provide a back-up,
upload data to the LCP before initialisation.
Restoring the default parameter settings is done by initiali-
sation of the frequency converter. Initialisation is carried
out through parameter 14-22 Operation Mode
(recommended) or manually.
•
•
Recommended initialisation procedure, via
parameter 14-22 Operation Mode
1.
2.
3.
4.
5.
Default parameter settings are restored during start-up.
This may take slightly longer than normal.
6.
7.
Manual initialisation procedure
1.
2.
Factory default parameter settings are restored during
start-up. This may take slightly longer than normal.
Manual initialisation does not reset the following frequency
converter information:
•
•
•
•
Danfoss A/S © 08/2015 All rights reserved.
Initialisation using parameter 14-22 Operation
Mode does not reset frequency converter settings,
such as operating hours, serial communication
selections, personal menu settings, fault log,
alarm log, and other monitoring functions.
Manual initialisation erases all motor,
programming, localisation, and monitoring data,
and restores factory default settings.
Press [Main Menu] twice to access parameters.
Scroll to parameter 14-22 Operation Mode and
press [OK].
Scroll to [2] Initialisation and press [OK].
Remove power to the unit and wait for the
display to turn off.
Apply power to the unit.
Alarm 80 is displayed.
Press [Reset] to return to operation mode.
Remove power to the unit and wait for the
display to turn off.
Press and hold [Status], [Main Menu], and [OK] at
the same time while applying power to the unit
(approximately 5 s or until audible click and fan
starts).
Parameter 15-00 Operating hours
Parameter 15-03 Power Up's
Parameter 15-04 Over Temp's
Parameter 15-05 Over Volt's
5 5
