Commissioning
To activate AEO, set parameter 1-03 Torque Characteristics to
[2] Auto Energy Optim. CT or [3] Auto Energy Optim. VT.

5.4.7 Automatic Motor Adaptation (AMA)

AMA is a procedure which optimises compatibility between
the frequency converter and the motor.
•
The frequency converter builds a mathematical
model of the motor for regulating output motor
current. The procedure also tests the input phase
balance of electrical power. It compares the
motor characteristics with the entered nameplate
data.
•
The motor shaft does not turn and no harm is
done to the motor while running the AMA.
•
Some motors may be unable to run the complete
version of the test. In that case, select [2] Enable
reduced AMA.
•
If an output filter is connected to the motor,
select [2] Enable reduced AMA.
•
If warnings or alarms occur, see
chapter 7 Diagnostics and Troubleshooting.
•
Run this procedure on a cold motor for best
results.
To run AMA
1. Press [Main Menu] to access parameters.
2. Scroll to parameter group 1-** Load and Motor
and press [OK].
Scroll to parameter group 1-2* Motor Data and
3.
press [OK].
4. Scroll to parameter 1-29 Automatic Motor
Adaptation (AMA) and press [OK].
5. Select [1] Enable complete AMA and press [OK].
6. Follow the on-screen instructions.
7. The test runs automatically and indicates when it
is complete.
8. The advanced motor data is entered in parameter
group 1-3* Adv. Motor Data.

5.5 Checking Motor Rotation

NOTICE
Risk of damage to pumps/compressors caused by motor
running in wrong direction. Before running the
frequency converter, check the motor rotation.
The motor runs briefly at 5 Hz or the minimum frequency
set in parameter 4-12 Motor Speed Low Limit [Hz].
MG16N102
Operating Instructions
1.
2.
3.
The following text appears: Note! Motor may run in wrong
direction.
4.
5.
NOTICE
To change the direction of rotation, remove power to the
frequency converter and wait for power to discharge.
Reverse the connection of any 2 of the 3 motor wires on
the motor or frequency converter side of the connection.

5.6 Local-control Test

1.
2.
3.
4.
In the event of acceleration or deceleration problems, see .
See chapter 7.3 Warning and Alarm Definitions for Frequency
Converter for resetting the frequency converter after a trip.

5.7 System Start-up

The procedure in this section requires wiring and
application programming to be completed. The following
procedure is recommended after application set-up is
completed.
1.
2.
3.
4.
5.
If warnings or alarms occur, see chapter 7.3 Warning and
Alarm Definitions for Frequency Converter or
chapter 7.4 Warnings and Alarm Definitions - Active Filter.
Danfoss A/S © 08/2015 All rights reserved.
Press [Main Menu].
Scroll to parameter 1-28 Motor Rotation Check and
press [OK].
Scroll to [1] Enable.
Press [OK].
Follow the on-screen instructions.
Press [Hand On] to provide a local start command
to the frequency converter.
Accelerate the frequency converter by pressing
▲
[ ] to full speed. Moving the cursor left of the
decimal point provides quicker input changes.
Note any acceleration problems.
Press [Off]. Note any deceleration problems.
Press [Auto On].
Apply an external run command.
Adjust the speed reference throughout the speed
range.
Remove the external run command.
Check the sound and vibration levels of the
motor to ensure that the system is working as
intended.
5 5
