Scope of Supply

-
-
-
-
-
-
-
-
-
-
-
-
-
-
-

Optional

If type 1 or type 2 overvoltage protection is desired, it can be installed in the Fronius String
Control 100/12 on the DIN rail provided for this purpose.

Technical data

Max. input voltage in no-load operation
Max. input current
Max. input current per fuse holder
Max. number of strings (with integrated solar module fuse)
Max. cable cross section for terminals on the solar module side
Max. cable cross section for the M12 connections on the invert-
er side
Number of measuring channels
Max. current per measuring channel
Screw joint for cable attachment to the solar module side
Screw joint for cable attachment to the inverter side
Degree of protection
Ambient conditions
Dimensions (without screw joints)
DATCOM power supply
Max. Solar Net current consumption
Weight
*)
1 Fronius String Control 100/12 (in the metal housing)
2 M32 metric screw joints including counter nuts
24 M16 metric screw joints including counter nuts
10 M16 threaded plugs
1 M20 metric screw joint including counter nut
1 M20 metric threaded plug
1 M25 metric screw joint including counter nut
1 M25 rubber insert
2 plastic bolts
1 silicone tube Ø 25 x 510 mm (for data communication cable)
1 silicone tube Ø 14 x 420 mm (for external power supply)
1 Set of seals (24 O-rings M16, 2 O-rings M32, 2 O-rings M20/M25)
1 DC Connector Kit (2 connection distributors including assembly accessories)
1 fire prevention leaflet
1 installation leaflet
applies for single and multi-core cables:
10 mm² with maximum cable diameter of 7 mm
10 mm² *)
95 mm²
-25 °C - +60 °C
-13 °F - +140 °F
500 x 350 x 145 mm
19.7 x 13.8 x 5.7 in.
via Solar Net
optional via a 12 V power supply
110 mA
13.67 lbs.
600 V
100 A
20 A
12
2
50 A
M16
M32
IP 55
6,2 kg
