LED
Type AC fault
Color Amber
On*
Off
Off
State
Off
On
Off
Flashing

5U84 enclosure fault LEDs

Visually inspect the front panel area for fault LEDs, then locate the component fault LEDs, based on general
location identified on the operator's panel or the drawer indicators. If a hardware issue prevents access to the
DSMU or CLI, this is the only option available. An asterisk (*) indicates a fault condition.
Operator's panel fault LEDs
The operator's (ops) panel uses several green and amber LEDs to identify various states. Use the amber fault
conditions identified on the operator's (ops) panel to direct you to the fault LEDs on suspect modules. The
asterisk (*) indicates a fault condition.
74 Chapter 9 Hardware installation and configuration issues
PCM OK Fan fault DC fault
Green Amber Amber
Off
Off On*
On Off
On Off On*
On* Off
Off On*
Flashing Off
Off Flashing
Figure 56 Power cooling module fault LEDs
Status
N/A
AC power not present on either PCM
AC power not present on this PCM
AC power present, power switch is on; PCM functional
PCM fan speed is out of tolerance
PCM fan fault
PCM hardware fault: over temperature, over voltage, over current
PCM is in standby mode
Firmware update to PCM in progress
