In the case of a system fault condition, identified in the state column with an asterisk (*), troubleshoot the fault.
See the baseboard management controller (BMC) system event log (SEL) for detailed information.
LED Type
Unit ID
Power on
or standby
Module
fault
Logical
status
Drawer 1,
Drawer 2
,
hardware
fault

Interpret drawer LED panels

Each storage enclosure drawer bezel contains 2 LED panels to reflect drawer status and activity, 1 for each
sideplane. Each sideplane represents a data path within the drawer. You can monitor the drawer LED panels
to determine drawer status in combination with the user interface content.
Color State
On
Green
Flashing (1s on, 1s
off)
Green On
Amber On
None Off
On*
Amber
Flashing*
Off
On*
Amber
Flashing*
Off
On*
Flashing (1s on, 1s
Amber
off)
Off
Figure 42 5U84 operator's panel LEDs
Status
Unit identification (UID) of storage enclosure (0-99)
SCSI enclosure services (SES) controlled UID or locate active
Storage enclosure power is on
Storage enclosure has AC power and is on standby as enclosure
comes online
Storage enclosure AC power is off
Ops panel completing 5s test
Module fault in rear panel area, when paired with module fault LED
Drive fault, when paired with drive fault LED
Unknown, invalid, or mixed module types, such as mixed drive
modules or PSUs
Vital product data (VPD) configuration error or 1²C bus fault
Storage enclosure rear panel area modules functioning properly
System component hardware fault: drive, cable, or fanout card
System component hardware change of status
Drive fault caused loss of redundancy
System software reports an informational condition for the array,
such as a rebuild operation, with corresponding drives registering a
fault
System component hardware functioning properly, no errors
Upper, lower drawer hardware fault: drive, cable, or fanout card
UID or locate active for Drawer 1, Drawer 2 sideplane or drive
Upper, lower drawer hardware functioning properly
Chapter 7 Operation of 5U enclosures 51
