SAS 4-port
=
12Gb/s
= iSCSI 4-port
Protocol LED
Figure 38 Port LEDs for SAS, fibre channel, iSCSI, and 10GBase-T iSCSI controller modules

Interpret SAS 12Gb/s expansion input/output module LEDs

Input/output modules (IOMs) in an expansion enclosure provide optional added storage. The IOM LEDs are
similar in function to controller module (CM) LEDs, reflecting host connectivity status and IOM fault conditions.
46 Chapter 6 Operation of 2U enclosures
Description
4-port 12Gb/s SAS link activity
Fibre channel link activity
iSCSI SFP link activity
iSCSI 10GBase-T link speed
iSCSI 10GBase-T link activity
Ethernet network port speed
Ethernet network port link activity Green
SAS expansion port status
= Fibre channel 4-port
= 10GBase-T iSCSI 4-port
Color State
Green On
Green or amber Flashing
Amber On
None Off
On
Green Flashing
Off
On
Green Flashing
Off
Green On
Amber On
None Off
On
Green Flashing
Off
On
Amber
Off
On
Off
Green On
Green or amber Flashing
Amber On
None Off
Status
Connected, link is up
Link activity
Connected, partial link is up
Not connected or link is down
Connected, link is up
Link activity
Not connected or link is down
Connected, link is up
Link activity
Not connected or link is down
10GbE rate
1GbE rate
Not connected or link is down
Connected, link is up
Link activity
Not connected or link is down
1000base-T negotiated rate
10/100base-T negotiated rate
Ethernet link is up
Ethernet link is down
Connected, link is up
Link activity
Connected, partial link is up
Not connected or link is down
