Figure 1 2U12 And 2U24 Front Panel Area - Quantum QXS Series Hardware Installation And Maintenance Manual

1
6
1 2 3 4 5
6
Item Description
1 Input button
2 Drive 0
3 Release latch, drive module
4 Anti-tamper lock, drive module
5 Drive 3
6 Operator's (ops) panel on left rack ear
flange
7 Drive 8
8 Status LEDs, drive module
9 Drive 11
10 Right rack ear cover
4 Chapter 2 System overview
2
3
7
8
7
Function
Selects and sets UID when combined with system Locate command
Responds to commands for drive logically numbered "0"
Allows drive module insertion onto and removal from the midplane and
slot
Prevents drive module removal when locked
Responds to commands for drive logically numbered "3"
Connects to midplane, provides users with storage enclosure information
and status
Responds to commands for drive logically numbered "8"
Provides users with drive module status
Responds to commands for drive logically numbered "11"
Acts as cosmetic cover over rack flange

Figure 1 2U12 and 2U24 front panel area

4
8
9
5
9 10
10
