Reset Function P20 - SMC Networks ITV23 Series Operation Manual

Initialize
"Initialize" is a function to return all the settings that the internal control constant is included to
an initial value. Please execute "initialize" only when the error is displayed, and this product
doesn't operate at all.
Please execute the "reset" function, when you want to return the pressure setting and the switch
setting to an initial value.
No
(1) Deactivate the key lock if necessary (refer to P14).
(2) Press SET-key for 2 seconds or more, then go to detail setting mode.
(3) To "F99" by using the △ and ▽ keys.
(4) Press SET-key.
Press △ and S keys for 5 seconds or more.
(5)
(Press SET-key to (3))
"Initialize" is executed, after 5 seconds.
(6)
(Release keys till less than 5 seconds to (4))
Returns to the state immediately after turning on of the power supply.
(7)
Activate the key lock if necessary (refer to P14).
Reset function
Clears the minimum and maximum pressure settings.
Operation
No
Deactivate the key lock if necessary (refer to P14).
(1)
Press the △ and ▽ keys
(2)
simultaneously for 3 seconds or more.
(3)
The settings are reset and returned to the condition before power was supplied.
(4)
Activate the key lock if necessary (refer to P14).
Reset contents.
Item
F_1
F_2
*(Note) Gain (G.L.) and sensitivity (S.L.) are not reset.
Key operation
Key operation
Reset contents
0%F.S.
100%F.S.
(Displayed alternately)
Turning off for 1 second
(current) pressure is displayed
is displayed for approx. 1 second
- 20 -
LED Display
⇔
flashes on the display
is displayed
LED Display
