Sensitivity setting
This setting can also be configured using the communication.
Adjusting the sensitivity changes the pressure correction operation near the set pressure point.
When the load capacity on the secondary side is large and hunting (unstable pressure) occurs,
decreasing the sensitivity tends to improve the hunting. However, as the pressure correction is
reduced, moderate pressure instability may occur.
In normal use, use the product in the condition when shipped, it is not always necessary to
adjust the sensitivity.
Key operation
No
(1) Deactivate the key lock if necessary (refer to P14).
Press SET-key for 2 seconds or more, then go to detail setting mode.
(2)
To "F02" by using the △ and ▽
(3)
keys.
(4) Press SET-key.
Set the SENSITIVITY by using the △
(5)
and ▽ keys.
(6) Press SET-key.
Press SET-key for 2 seconds or more, then go out from detail setting mode.
(7)
(Select the menu with △ or ▽ keys, then jump to another item.)
(8) Activate the key lock if necessary (refer to P14).
Relation between setting and sensitivity
Sensitivity Sharp
Setting of
sensitivity
* Indicates the initial value.
⇔
⇔
Sensibility
- 18 -
LED Display
(displayed alternately)
(Blink and change the rightest digit)
(displayed alternately)
Dull
