SMC Networks ITV23 Series Operation Manual page 10

Parameter name
Function
Value
* Indicates the initial value.
Set point.
Gain setting
The response time can be changed by tuning the gain.
If the over-shoot is large, decreasing the gain tends to improve it, but
the responsiveness becomes slower.
Conversely, when the gain is increased, the response time tends to
be faster, but stability will be lost, which may cause hunting (unstable
pressure).
In normal use, use the product in the condition when shipped, it is not
always necessary to adjust the gain.
Initial value：Gain 9
Setting
*
overshoot
Gain
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
- 9 -
Gain 0
Gain 1
Gain 2
Gain 3
Gain 4
Gain 5
Gain 6
Gain 7
Gain 8
Gain 9
Gain A
Gain B
Gain C
Gain D
Gain E
Gain F
Set point.
Becomes gentle.
Slow
Quick
