Detail setting mode
No
(1) Deactivate the key lock if necessary (refer to P14).
(2) Press SET-key for 2 seconds or more.
△key
△key
△key
(3)
△key
(4) In state of 3, press SET-key for 2seconds or more.
(5) Return to (current) pressure display.
(6) Activate the key lock if necessary (refer to P14).
Key operation and LED display
⇔
↑
↓
▽key
⇔
↑
↓
▽key
⇔
↑
↓
▽key
⇔
(displayed alternately)
Press SET-key
To "GAIN" (refer to P17)
(displayed alternately)
Press SET-key
▽key
To "SENSITIVITY" (refer to P18)
(displayed alternately)
Press SET-key
To "ZERO CLEAR" (refer to P19)
(displayed alternately)
Press SET-key
To "INITIALIZE" (refer to P20)
- 16 -
