MES SQA-V Gold Service Manual page 7

SQA-V
and Service Manual 24_Apr_2014
Specimen Testing Supplies

Measurement capillary:
capillary. (Testing depth of capillary section: 300-micron; Cuvette section:
10 mm).

Standard laboratory slide:
Operating System

Control:

Analysis Time:
Test – 5 minutes (9 minutes in version 2.43).

Software:
functions, runs algorithms for test measurements (according to WHO
guidelines), and operates visual and automated screens. System can be
upgraded from a PC CD-ROM.

Sample Testing Temperature:
20-25° C / 68-77° F. Motility results will be impacted by heating the specimen.

Motility channel input signal:

Spectrophotometer channel input signal:
5V.
Quality Control

Internal:

External:
systems using commercially available assayed control material: "QwikCheck-
beads™" (product of Medical Electronic Systems) or Stabilized Sperm as a
non-assayed control in version 2.45 and higher.
PC Compatibility
Minimum requirements for V-Sperm software

PC: 1 GHz processor, Pentium 3

RAM: 256 MB

AGP-video display card

Video color: At least 16 bit (65,535)

CD ROM drive

200 MB free hard disk space

Video resolution:

Operating system compatibility:

Ports: One serial; two USB ports

Monitor:
Required Software

V-Sperm software for SQA-V system and I-button set-up, archive and
CONTROL reporting
real time visualization interface between PC and SQA-V visualization system,
data analysis, video/picture capture and archives test records.

Excel/Word for exporting files and clips
Operational Temperature and Humidity

System is operational at 15-38

NOTE: SQA-V operates in a wide range of ambient temperatures however the
system is calibrated to measure semen samples at room temperature:
º
20-25 C (68-77
Disposable, plastic, positive displacement testing
20 micron depth, 22 x 22 mm cover-slip.
Keypad
Normal Test – 75 seconds; High Sensitivity/Postvasectomy
Resides on flash memory and drives all man-machine interface
Electronic Self-Test and Auto-Calibration.
Counts can be run on the SQA-V automated and visualization
with at least 16 MB of RAM memory
Minimum 640 x 480
15" color
also permits user to benefit from many features such as
º
º
F).
7
Calibrated for room temperature only
Analog, up to 5V.
Modulated (1 kHz) analog, up to
for image capturing
Windows XP, VISTA (Windows 7 pending)
C.
