5. Sample size out of range

If the sample size has been entered as > 50 ml the calculated parameters will not import to
the V-Sperm software.

6. I-Button warning screen


I-BUTTON NOT PROPERLY
ACTIVATED

Remove the I-button

Press ESC and Retry

EMPTY I-BUTTON INSERTED

Press ESC and Retry with a
new I-Button

I-BUTTON WARNING

This screen will be
displayed when less than
10 tests remain in the
SQA-V

Insert a new I-Button

7. COMMUNICATION ERROR


A communication error may
occur in one of the following
cases:

Defective wire connection:
The cable that connects the
optical board to the main
board is not well connected
or was damaged

Hardware problem
COMMUNICATION ERROR
CALL FOR TECHNICAL SUPPORT
34
