 Under UPLOAD A NEW LICENSE, select a
LICENSE FILE.
 Click on UPLOAD.
The upload will take a few seconds.
The new license is listed in the ACTIVATED
LICENSES dialog.
 Reboot the device and log in again. The new function is only available after a restart of the headend.

5.12. CASimulcrypt (with MKS 1-02)

The setup for the conditional access system requires the installation and configuration of a CAS server, which generates ECMs
and EMMs, among other things. Setting up a CAS server is not described in this document.
To configure the settings for the headend unit, you must have a corresponding licence. If this licence is activated in the
headend, the necessary settings can be made under CAS.
 Click on CAS SETTINGS.
Several fields and tables for the CAS settings are displayed.

5.12.1. Global Settings

Enable Simulcrypt: Enable or disable Simulcrypt (license needed to activate).
Network Interface used for simulcrypt-related network traffic, option is Control (Configuration port).
The IP address of the port must be configured for EMMG (CAS server), see 5.3 on page 33.
EMMG Listening Port: TCP port configured in EMMG (CAS server) to connect the headend.

5.12.2. Scrambling Control Groups (SCG)

This table lists all Scrambling Control Groups used in the device. Programs connected to the same SCG are scrambled at the
same time with the same control word (encryption key). Each SCG can contain one or more program. Programs are connected
to SCGs at page Phase2 (see 5.11.7 on page 46).
