- Page 1 CHP - Compact High Performance Headends AIP 8-00 DAB/DAB+/FM into IP Radio Streamer Operation instructions...
-
Page 2: Table Of Contents
Editing the IP addresses .................................. 18 5.6. Password ......................................19 5.7. View the log entries ..................................19 5.8. SMARTPortal ....................................20 Technical specifications .................................... 21 Page 2 of 22 AXING-BA_AIP-8-00.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2023-07-04... - Page 3 Hereby AXING AG declares that the CE marked products comply with the valid EU guidelines. Hereby AXING AG declares that the device is additionally in compliance with Directive 2014/53/EU. The complete EU declaration of conformity is available at: https://axing.com/en/downloads/ce/.
-
Page 4: Product Description
1.2. Scope of delivery 1 × IP Streamer 1 × AC power cord 1 × Quick start guide 1 × Safety instructions Page 4 of 22 AXING-BA_AIP-8-00.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2023-07-04... -
Page 5: Product Description
The FM or DAB+ programmes are then converted into eight SPTS and can be distributed via LAN using suitable switches. In a further step, the SPTS can be converted to DVB-C/T/T2 via an additional MIE headend. 2023-07-04 | Technical improvements, changes in design, printing- and other errors reserved. | AXING-BA_AIP-8-00.pdf Page 5 of 22... -
Page 6: Graphical User Interface
1.3.2. SMARTPortal The AXING SMARTPortal connects each AXING headend device with a cloud-based portal and thus provides worldwide access to the devices. The connection is password-saved and scrambled. The only requirement on site is an internet connection of the device e. g. via LAN, EoC, EoC-WLAN-Bridge, 3G/LTE-Router. -
Page 7: Mounting And Installation
Connect the headend to a mains socket using the enclosed mains cable. 2.4. RF Installation The AIP 8-00 has eight F sockets. Connect them to the DAB/DAB+/FM antennas. Use high-shielded coaxial cables with F connectors. 2023-07-04 | Technical improvements, changes in design, printing- and other errors reserved. | AXING-BA_AIP-8-00.pdf... -
Page 8: Configuration
If needed, the devices can be integrated in a network. For this application, some changes must be applied to the network configuration. Menu item MAINTENANCE > IP ADRESS. Page 8 of 22 AXING-BA_AIP-8-00.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2023-07-04... -
Page 9: Front Page
• Disabled Output is disabled by in Phase 3 The service name, the IP address and the Bitrate and are also shown. 2023-07-04 | Technical improvements, changes in design, printing- and other errors reserved. | AXING-BA_AIP-8-00.pdf Page 9 of 22... -
Page 10: Initialization
In the field Source, select whether the tuner should receive FM or DAB. If FM is selected, enter the input frequency. If DAB is selected, choose an input channel. Page 10 of 22 AXING-BA_AIP-8-00.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2023-07-04... - Page 11 When a transmitter is found, the status goes to Locked and BER (DAB/DAB+ only), Level and SNR are displayed. If it is a DAB channel, under FOUND DAB SERVICES the Programs in this channel are shown. 2023-07-04 | Technical improvements, changes in design, printing- and other errors reserved. | AXING-BA_AIP-8-00.pdf Page 11 of 22...
-
Page 12: Phase 2 - Programs For Outputs
The file will be uploaded and shown in the Service Logo field. Click + CHANCE, to change a logo or REMOVE to remove it. Click SAVE CHANGES to store the settings. Page 12 of 22 AXING-BA_AIP-8-00.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2023-07-04... -
Page 13: Phase 3 - Settings For Outputs
In case CBR selected, CBR bitrate must entered: 150 … 2500 kbps. Edit a Destination IP and a Destination port for the Output. Click SAVE CHANGES to store the settings. 2023-07-04 | Technical improvements, changes in design, printing- and other errors reserved. | AXING-BA_AIP-8-00.pdf Page 13 of 22... -
Page 14: Maintenance
Under Device information, you will find the following information: • Serial number of the device • Software version of the controller • Software version of each encoder Page 14 of 22 AXING-BA_AIP-8-00.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2023-07-04... -
Page 15: Updating The Software
Note: The device consists of a controller and 8 encoders. Each unit must be updated separately. Click MAINTENANCE > SW UPDATE. Download You can find software updates by entering the article in the search field at www.axing.com. Download the update file to your computer. Unpack it. -
Page 16: Down- Or Upload Of A Configuration To The Device
In the CONFIG area, you can download the device configuration to your computer, upload a device configuration or delete the device configuration. By deleting the configuration, the unit is reset to the delivery status. Page 16 of 22 AXING-BA_AIP-8-00.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2023-07-04... -
Page 17: Rebooting Hard- Or Software
The software of the controller or an encoder is rebooted. Hardware Reboot Click on HW REBOOT 1-4 or HW REBOOT 5-8. A hardware reset for the corresponding encoders is done. 2023-07-04 | Technical improvements, changes in design, printing- and other errors reserved. | AXING-BA_AIP-8-00.pdf Page 17 of 22... -
Page 18: Editing The Ip Addresses
192.168.0.160 for the controller • 192.168.0.161 … 168 for the encoders. After changing address data, click SAVE CHANGES. The data is stored. Page 18 of 22 AXING-BA_AIP-8-00.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2023-07-04... -
Page 19: Password
Click MAINTENANCE > LOGS. Under LOGS you can see the log entries of the device. Click CLEAR to delete all entries. 2023-07-04 | Technical improvements, changes in design, printing- and other errors reserved. | AXING-BA_AIP-8-00.pdf Page 19 of 22... -
Page 20: Smartportal
In the field User key, enter the user key that you received when registering at SMARTPortal. Click on SAVE. The data is saved, the device is rebooted and the connection to the SMARTPortal is established. Page 20 of 22 AXING-BA_AIP-8-00.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2023-07-04... -
Page 21: Technical Specifications
Dimensions (W × H × D) 480 × 47 × 253 mm appr. Weight 3.50 kg Comments * Encrypted, cloud-based application for configuration, monitoring and remote maintenance 2023-07-04 | Technical improvements, changes in design, printing- and other errors reserved. | AXING-BA_AIP-8-00.pdf Page 21 of 22... - Page 22 Operation instructions | AIP 8-00 Page 22 of 22 AXING-BA_AIP-8-00.pdf | Technical improvements, changes in design, printing- and other errors reserved. | 2023-07-04...
