7. Technical specifications

7.1. MIP 8-00 | MIP 8-06 | MIP 16-00 | MIP 16-06
Type
Inputs
Number of tuners
Connector
Frequency range
Input level
LNB voltage
Max. LNB current
CI slots
Input modulation
Type
Compliance
Supported input transport streams
Error correction
Symbol rate
IPTV output
Transport streams SPTS | MPTS
Total net data rate
Data rate per tuner
Supported transport protocols
Supported application protocols
2023-10-05 | Technical improvements, changes in design, printing- and other errors reserved. | AXING-BA_MIP-8-16-0x.pdf
MIP 8-00 MIP 8-06
8 × DVB-S/S2/S2X/T/T2/C
8 × F-female 8 × F-female
900...2150 MHz @ DVB-S/S2/S2X
50...898 MHz @ DVB-/T/T2
43...84 dBµV @ DVB-S/S2/S2X
13/17 V; 22 kHz on/off; DiSEqC 1.0
-
QPSK/8PSK/ 8APSK/16APSK/32APSK @ DVB-S/S2/S2X
QAM16, QAM32, QAM64, QAM128, QAM256 @ DVB-C
QPSK, QAM16, QAM66 @ DVB-T
QPSK, QAM16, QAM64, QAM256 @ DVB-T2
DVB-S2 = EN 302 307-1V1.4.1
DVB-S2X = EN 302 307-2V1.1.1
DVB-C = EN 300 429/ITU-TJ.83 Annex A/C
MPEG-2 ISO/IEC 13818 | MPEG-4 ISO/IEC 14496
1.5...45 MS/s (<40MSymbol/s in 32APSK) @ DVB-S
512 | 8 512 | 8
MIP 16-00
16 × DVB-S/S2/S2X/T/T2/C
16 × F-female
50...898 MHz @ DVB-C
49...84 dBµV @ DVB-C
39...84 dBµV @DVB-/T/T2
250 mA per input
1000 mA per device
6 -
DVB-S = EN 300 421
DVB-T = EN 300 744
DVB-T2 = ETSI EN 302 755
auto
1...7.2 Mbaud @ DVB-C
512 | 16
800 Mbps
125 Mbps
UDP
RTP
MIP 16-06
16 × F-female
6
512 | 16
