MIP 8-00N | MIP 8-03N | MIP 12-00N | MIP 12-03N

7.2.
Type
Inputs
Number of tuners
Connector
Frequency range
Input level
LNB voltage
Max. LNB current
CI slots
Input modulation
Type
Compliance
Input transport streams
Error correction
Symbol rate
Transportstreams
Modifiable program information
LCN
Encryption
IP output
Transportstreams
Total net data rate
Data rate per tuner
Transport protocols
Application protocols
2023-10-05 | Technical improvements, changes in design, printing- and other errors reserved. | AXING-BA_MIP-8-16-0x.pdf
MIP 8-00N MIP 8-03N
8 × DVB-S/S2/S2X/T/T2/C
8 × F-female
900...2150 MHz @ DVB-S/S2/S2X
50...898 MHz @ DVB-C
50...898 MHz @ DVB-/T/T2
43...84 dBµV @ DVB-S/S2/S2X
49...84 dBµV @ DVB-C
39...84 dBµV @ DVB-/T/T2
13/17 V; 22 kHz on/off; DiSEqC 1.0
1000 mA per device
- 3
QPSK, 8PSK, 8APSK, 16APSK, 32APSK @ DVB-S/S2/S2X
QAM16, QAM32, QAM64, QAM128, QAM256 @ DVB-C
QPSK, QAM16, QAM64 @ DVB-T
QPSK, QAM16, QAM64, QAM256 @ DVB-T2
DVB-S = EN 300 421
DVB-S2 = EN 302 307-1V1.4.1
DVB-S2X = EN 302 307-2V1.1.1
DVB-C = EN 300 429/ITU-TJ.83 Annex A/C
DVB-T = EN 300 744
DVB-T2 = ETSI EN 302 755
MPEG-2 ISO/IEC 13818 | MPEG-4 ISO/IEC 14496
1.5...45 MS/s (< 40 MS/s in 32APSK) @ DVB-S/S2/S2X
1...7.2 Mbaud @ DVB-C
Program name, SID remapping, PID remapping, PID filtering* TSID, ONID
DVB-CSA*, DVB-CISSA*, ATIS-IDSA*, AES-ECB*, AES-CBC*
512 × SPTS | 8 × MPTS
MIP 12-00N
12 × DVB-S/S2/S2X/T/T2/C
12 × F-female
250 mA per input
-
auto
Yes
512 × SPTS | 12 × MPTS
900 Mbps
125 Mbps
UDP
RTP
MIP 12-03N
3
