6 Ratings

6.1 Recommended Operating Conditions

Table 4 provides a comprehensive guideline for the optimal use of the Portenta Hat Carrier, outlining typical
operating conditions and design limits.
VIN from onboard screw terminal
+5 VDC from onboard screw terminal (J9) of the carrier
USB-C® from the connected Portenta family board
Current delivered by the carrier
+5 VDC from the 40-pin header connector of the carrier
Operating ambient temperature
Table 4: Recommended operating conditions of the Portenta Hat Carrier
1
The power supply connected to the onboard screw terminal block powers the carrier, the connected Portenta
family board, and compatible Raspberry Pi® Hats. The onboard screw terminal connector has an integrated reverse
polarity protection.
8 / 34
Parameter
1
(J9) of the carrier
Arduino® Portenta Hat Carrier
Arduino® Portenta Hat Carrier
Symbol
VIN
TERMINAL
V5
TERMINAL
V5
USBC
I
CARRIER
V5
HEADER
T
OP
Min Typ Max Unit
7.0 - 32.0
- 5.0 -
- 5.0 -
- - 1.5
- 5.0 -
-40 - 85
Modified: 25/10/2023
V
V
V
A
V
°C
