1.4 Assembly Overview

Example of a typical assembly including an Arduino® Portenta H7 and Arduino® Portenta Cat. M1/NB IoT GNSS

2 Ratings

2.1 Recommended Operating Conditions

Symbol Description
V
Input Voltage from Portenta
cc
V
Active GNSS Antenna Bias Voltage
GNSS
T
Operating Temperature
OP
(1)
: See Portenta datasheet
(2)
: Temperatures under -30°C may cause instability in the TX62 operation.

2.2 Power Consumption

Symbol Description
P
Power consumption in standby
STDBY
P
Power consumption for GPS geo-location at 1 Hz
GPS
P
Power consumption for sending data to Arduino Cloud at 1 Hz
CLOUD
Power consumption for GPS geo-location and sending data to Arduino
P
GPSCLOUD_LP
Cloud once per hour
5 / 13
Arduino® Portenta Cat. M1/NB IoT GNSS
2
Arduino® Portenta Cat. M1/NB IoT GNSS Shield
Shield.
Min
3.2
2.9
-40
Shield
Typ Max Unit
3.3 3.4 V
3 3.1 V
25 85 °C
Min Typ Max Unit
TBC
TBC
TBC
TBC
Modified: 12/10/2022
mW
mW
mW
mW
