16-Pin Header (J6) - Arduino ASX00049 Product Reference Manual

Pin
Silkscreen
number
31 PWM3
32 TX1
33 PWM4
34 GND
35 I2S WS
36 PWM5
37 PWM6
38 I2S SDI
39 GND
40 I2S SDO

7.2.2 16-Pin Header (J6)

Pin
Silkscreen
number
1 A0
2 A1
3 A2
4 A3
5 A4
6 A5
7 A6
8 A7
9 PWM7
10 PWM8
11 LICELL
12 PWM4
13 3V3
14 TX2
15 GND
16 RX2
11 / 34
Portenta HD
Power Net
Standard Pin
GND
GND
Table 5: Raspberry Pi® 40-Pins Connector (J5) pinout
Portenta HD
Power Net
Standard Pin
ANALOG_A0
ANALOG_A1
ANALOG_A2
ANALOG_A3
ANALOG_A4
ANALOG_A5
ANALOG_A6
ANALOG_A7
+3V3_PORTENTA
GND
Table 6: 16-Pin Header (J6) pinout
Arduino® Portenta Hat Carrier
Arduino® Portenta Hat Carrier
PWM_3
SERIAL1_TX
PWM_4
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
GND
24, J2-33, J2-44, J2-57, J2-70
I2S_WS
PWM_5
PWM_6
I2S_SDI
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
GND
24, J2-33, J2-44, J2-57, J2-70
I2S_SDO
PWM_7
PWM_8
LICELL
GPIO_0
VCC J2-23, J2-34, J2-43, J2-69
SERIAL2_TX
J1-22, J1-31, J1-42, J1-47, J1-54,
GND
J2-24, J2-33, J2-44, J2-57, J2-70
SERIAL2_RX
High-Density Pin
J2-65
J1-33
J2-67
J1-58
J2-60
J2-62
J1-60
J1-62
High-Density Pin
J2-73
J2-75
J2-77
J2-79
J2-74
J2-76
J2-78
J2-80
J2-64
J2-66
J2-7
J2-46
J2-26
J2-28
Modified: 25/10/2023
Interface
UART 1 TX
I2S WS
I2S SDI
I2S SDO
Interface
RTC Power
Source
UART 2 TX
UART 2 RX
