7.2 Full Pinout Table

The full pinout of the Portenta Hat Carrier is available in the following tables sorted by element/connector.
7.2.1 Raspberry Pi® 40-Pins Connector (J5)
Pin
Silkscreen
number
1 3V3
2 5V
3 I2C2 SDA
4 5V
5 I2C2 SCL
6 GND
7 PWM0
8 TX3
9 GND
10 RX3
11 GPIO2
12 I2S CK
13 GPIO6
14 GND
15 SAI D0
16 SAI CK
17 3V3
18 SAI FS
19 SPI1 COPI
20 GND
21 SPI1 CIPO
22 PWM1
23 SPI1 SCK
24 SPI1 CE
25 GND
26 PWM2
27 I2C0 SDA
28 I2C0 SCL
29 RX1
30 GND
10 / 34
Portenta HD
Power Net
Standard Pin
+3V3_PORTENTA
+5V
+5V
GND
GND
GND
+3V3_PORTENTA
GND
GND
GND
Arduino® Portenta Hat Carrier
Arduino® Portenta Hat Carrier
VCC
VIN J1-21, J1-24, J1-32, J1-41, J1-48
VIN J1-21, J1-24, J1-32, J1-41, J1-48
I2C2_SCL
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
GND
24, J2-33, J2-44, J2-57, J2-70
PWM_0
SERIAL3_TX
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
GND
24, J2-33, J2-44, J2-57, J2-70
SERIAL3_RX
GPIO2
I2S_CK
GPIO_6
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
GND
24, J2-33, J2-44, J2-57, J2-70
SAI_D0
SAI_CK
VCC
SAI_FS
SPI1_MOSI
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
GND
24, J2-33, J2-44, J2-57, J2-70
SPI1_MISO
PWM_1
SPI1_CK
SPI1_CS
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
GND
24, J2-33, J2-44, J2-57, J2-70
PWM_2
I2C0_SDA
I2C0_SCL
SERIAL1_RX
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
GND
24, J2-33, J2-44, J2-57, J2-70
High-Density Pin
J2-23, J2-34, J2-43, J2-69
J2-45
J2-47
J2-59
J2-25
J2-27
J2-50
J1-56
J2-58
J2-53
J2-49
J2-23, J2-34, J2-43, J2-69
J2-51
J2-42
J2-40
J2-61
J2-38
J2-36
J2-63
J1-44
J1-46
J1-35
Modified: 25/10/2023
Interface
I2C 2 SDA
I2C 2 SCL
UART 3 TX
UART 3 RX
I2S CK
SAI D0
SAI CK
SAI FS
SPI 1
MOSI
SPI 1
MISO
SPI 1 CK
SPI 1 CS
I2C 0 SDA
I2C 0 SCL
UART 1 RX
