5.3 Other Features

Additional onboard storage MicroSD card slot for data logging and media purposes (J7) (x1)
Video support Only with the Portenta X8 board through its onboard USB-C®
Camera support
CAN bus support Onboard transceiver (J9) (x1)
Push button
DIP switch (with two sliders)
7 / 34
Feature Description
USB USB-A 2.0 connector for data logging and external peripherals (J4) (x1)
Only with the Portenta X8 board through the onboard MIPI camera connector
of the carrier (J10)
Ethernet RJ45 connector (J8) (x1)
Push button (x1) used to flash the bootloader by making a long press
during boot. This button can also be used as a user-programmable button
connected to GPIO1
Power LED (x1)
User-programmable LED (x1) connected to the GPIO3 pin of the onboard
LEDs
High-Density connectors
ETH CENTER TAP: Enable/Disable Ethernet (OFF position to enable for
Portenta X8, ON position to enable for Portenta H7/C33)
BTSEL: Reserved for future applications
Table 3: Other important features of the Portenta Hat Carrier
