Ratings; Absolute Maximum Ratings; Recommended Operating Conditions; Functional Overview - Arduino AKX00034 Product Reference Manual

2 Ratings

2.1 Absolute Maximum Ratings

Symbol Description
T
Maximum thermal limit
Max
V
Maximum input voltage from battery input
BattMax
V
Maximum input voltage from solar panel
SolarMax
A
Maximum current through relay switch
RelayMax
P
Maximum Power Consumption
Max

2.2 Recommended Operating Conditions

Symbol Description
T Conservative thermal limits
V
Input voltage from battery input
Batt
V
Input voltage from solar panel
Solar

3 Functional Overview

3.1 Board Topology

Top View
8 / 25 Arduino® Edge Control
Arduino® Edge Control
Min Typ
-40 20
-0.3 12
-20 18
- -
- -
Min Typ Max
-15 20 60
- 12 -
16 18 20
Modified: 17/12/2021
Max Unit
85 °C
17 V
20 V
2.4 A
5000 mW
Unit
°C
V
V
