Wiring Diagram - Directed DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
White Conn.
(at Main Body ECU)
1
(+)12V:
Green or Black, pin 1
Black Steering Lock conn.
(at steering lock conn.)
Black
ENGINE
START 5 4
Connector
STOP
10 9 8
Black or Blue PTS
Button Conn.
(at PTS switch)
7 403.TL8 3.06 2020 Lexus GX 460 (Smart Key)
©2023 Directed. All rights
(-) Lock: Violet or Red,pin 29
(-) Unlock:
Lt. Blue or
Green, pin 2
Autolight:
Black or White, pin 8
CUT
(-) SLP: Lt. Green
or Blue, pin 4
(-) PTS: Yellow or Lt.Green, pin 5
3 2 1
7 6
20 22 23 27 29 White Connector
8 10 12 13 14 15 16 17 18 (at Main Body ECU)
2 5
HS CAN high:
Red or Blue, pin 14
HS CAN Low:
White, pin 13
HS CAN High: Tan/Black: 3
Autolight Interr. (conn. side): Yellow: 8
Autolight Interr. (veh. side): Orange/Yellow: 9
(-) Ground: Yellow/Red: 11
(-) SLP Output: Brown/Red: 12
(-) PTS Output: Green/Black: 2
(-) Unlock Output: Red/Black: 4
(-) Lock Output: Blue/Red: 12
HS CAN Low: Tan: 4
(+) 12V Input: Red: 13
(-) Ground: Black: 14
).
You can connect to either a
XL202 RFTD OR a SmartStart
module.
Refer to the SmartStart/XL202
Installation Notes for more
information.
6: White/Black:
(-) Hood
Remote Start Safety
Override Switch
Hood Pin
