2.3.3 Motor Specification And Dimension

2.3.3.1 □40mm Specification and Dimension
□ 40mm Series
□ 40mm Series
Series
^ Preferred Model & Winding Letter
Base Model Number
(with 2500 PPR incremental encoder non-sealed plastic
connectors, no brake)
Rated Output Power
Rated Speed
Max. Mechanical Speed
Rated Torque
Continuous Stall Torque
Peak Torque
Rated Current
Continuous Stall Current
Peak Current
Voltage Constant ±5%
Torque Constant ±5%
Winding Resistance (Line-Line)
Winding Inductance (Line-Line)
Inertia (with encoder)
Inertia - With Brake Option
Thermal Resistance (mounted)
Thermal Time Constant
Heat Sink Size
Shaft Load - Axial
Shaft Load - Radial (End of Shaft)
Weight (with std. encoder)
Weight - With Brake Option
Shaft Load: (L life, 20,000 hours, 2,000 RPM)
10
400-820-9661
UL File
Insulation Class
IP rating
Installation location
Ambient temperature
Ambient humidity
Altitude (maximum)
Vibration Resistance
Rotor Poles
watts
rpm
rpm
Nm
Nm
Nm
A (rms)
A (rms)
A (rms)
V (rms) / K rpm
Nm / A (rms)
Ohm ±10% @25°C
mH (typ.)
kg m^2
kg m^2
°C / W
Minutes
mm 120 x 120 x 5 Alumnum
(max.)
(max.)
15
E465363
Class B(130℃)
IP65 (except shaft through hole and cable end
connetor)
Indoors, free from direct sunlight, corrosive gas,
inflammable gas
Operating 0 to 40°C, Storage -20 to 65°C
85%RH or lower (free from condensing)
Operating 1,000m
2
49 m/s
8
SM0401 - 50 Watt
^ A
SM0401
AE2-KCD-NNV
50
3000
6000
0.19
0.2
0.48
0.7
1.75
1.7
17
0.283
27
26
0.0232 X 10
-4
0.0298 X 10
-4
2.9
12
50 N / 11 Lb
50 N / 11 Lb
0.4 kg / 0.9 Lb
0.65 kg / 1.4 lb
SM0402 - 100 Watt
^ A
SM0402
AE2-KCD-NNV
100
3000
6000
0.32
0.34
0.93
1.2
1.27
3.6
16.6
0.271
9.7
11.5
0.0428 X 10
-4
0.0494 X 10
-4
2.4
14.5
120 x 120 x 5 Alumnum
50 N / 11 Lb
60 N / 13.5 Lb
0.55 kg / 1.2 Lb
0.8 kg / 1.8 lb
