All manuals and user guides at all-guidesbox.com Istruzioni per installazione, uso e manutenzione Installation, use and maintenance instructions 安装、使用以及维护说明书 Bruciatori industriali di gas Industrial gas burners 强制通风燃气燃烧器 Funzionamento bistadio progressivo o modulante Progressive two-stage or modulating operation 平滑二段火运行或比例调节 CODICE - CODE - 代码 MODELLO - MODEL - 型号...
Page 2
All manuals and user guides at all-guidesbox.com...
Page 3
All manuals and user guides at all-guidesbox.com Avvertenze generali Informazioni sul manuale Questo manuale costituisce parte integrante del prodotto e non va da esso separato. Leggerlo attentamente in quanto fornisce importanti indicazioni riguardanti l'installazione, l'uso e la manutenzione del bruciatore; conservarlo con cura per ogni ulteriore consultazione. Destinatari Questo manuale è...
All manuals and user guides at all-guidesbox.com Indice CAPITOLO Introduzione ....pagina 3 Descrizione codice di selezione ....3 Specifica del tipo e codifica bruciatori .
All manuals and user guides at all-guidesbox.com Introduzione Descrizione codice di selezione Specifica del tipo e codifica bruciatori TIPO CODICE DB 6 M CO TC A-0 DB 4 SM CO1 TC 20080068 Alimentazione aria DB 6 SM CO1 TC 20075270 comburente A-0 = dal basso A-90 = da destra...
All manuals and user guides at all-guidesbox.com Descrizione del bruciatore Dati tecnici Modello DB 4 SM CO1 A0 DB 6 SM CO1 A0 Tipo 80068X 75270X Capacità Min./Max. gas naturale [kW] 1200/3000 ÷ 5000 1400 ÷ 7800 Regolazione potenza Modulante Combustibile Gas naturale (G 20) - PCI 10 Gas naturale (G 25) - PCI 8,6 kWh/Nm...
All manuals and user guides at all-guidesbox.com CAPITOLO Descrizione del bruciatore Componenti del bruciatore 20076243 Fig. 2 Legenda 12 Pressostato aria Cassa d’aria 13 Pressostato gas di massima con presa di pressione Coperchio 14 Flangia attacco gas Servomotore 15 Otturatore 16 Leva per movimento testa di combustione Cassetta con morsettiera per collegamenti elettrici Flangia di attacco alla caldaia...
All manuals and user guides at all-guidesbox.com CAPITOLO Descrizione del bruciatore Dimensioni di ingombro 20076244 Fig. 3 DB 4 1550 1024 ø 312 DB 6 1518 1024 ø 363 DIMENSIONI FLANGE DB4 SM Collegamento canale aria Fissaggio alla caldaia Alimentazione gas 3 5 0 6 5 , 5 D7549...
Page 9
All manuals and user guides at all-guidesbox.com CAPITOLO Descrizione del bruciatore DIMENSIONI FLANGE DB6 SM Collegamento canale aria Fissaggio alla caldaia Alimentazione gas 3 8 0 1 6 0 D7549 4 9 5 DN 80 D8325 D3974 Fig. 8 Fig. 9 Fig.
All manuals and user guides at all-guidesbox.com CAPITOLO Descrizione del bruciatore Perdite di carico lato aria (rilevata a monte serranda con apertura completa) D12215 3000 4000 5000 6000 7000 8000 Potenza bruciatore Pb [kW] Fig. 10 Le curve di pressione si riferiscono alle condizioni di regolazione della testa di combustione secondo grafico di pag. 13. Vedere Paragrafo 5.1.
All manuals and user guides at all-guidesbox.com CAPITOLO Descrizione del bruciatore Perdite di carico lato gas La pressione del gas in funzio- Perdite testa di combustione D7541 ne della potenza massima svi- luppata dal bruciatore è data dalle curve di Fig. 11. Rappresenta la perdita di carico della testa di combustione.
All manuals and user guides at all-guidesbox.com Installazione Rimozione viti di blocco dell’otturatore Prima di montare il bruciatore sulla caldaia rimuovere le viti e i dadi 1)- 2)(Fig. 13). Sostituirli con le viti 3) M12x16 fornite a corredo. Lunghezza boccaglio La lunghezza del boccaglio va scelta secondo le indicazioni del costrut- D12015 tore della caldaia e, in ogni caso, deve essere maggiore dello spessore...
All manuals and user guides at all-guidesbox.com Alimentazione al bruciatore Schema generale di alimentazione gas (esempio) D7543 max. 500 mbar 0,5 ÷ 4 bar Fig. 16 Legenda Giunto antivibrante PGm Pressostato gas di minima Filtro gas Farfalla gas HPG Regolatore alta pressione gas Valvola limitatrice di pressione con scarico in atmosfera Regolatore bassa pressione gas Ventilatore...
All manuals and user guides at all-guidesbox.com CAPITOLO Alimentazione al bruciatore Collegamenti elettrici D9854 Fig. 17 Morsettiera bruciatore Pressostato aria PGM Pressostato gas di massima Servomotore Fotocellula UV Trasformatore di accensione Terra bruciatore...
All manuals and user guides at all-guidesbox.com Preparazione all’avviamento Regolazione della testa di combustione Allentare la vite 1) e ruotare il settore graduato 2) in funzione del diagramma Fig. 19. Il sistema permette una regolazione ottimale anche al minimo del campo di lavoro.
All manuals and user guides at all-guidesbox.com CAPITOLO Preparazione all’avviamento Posizione elettrodi Controllare che la sonda e l’elettrodo siano posizionati come in Fig. 20. 20076847 Fig. 20...
All manuals and user guides at all-guidesbox.com CAPITOLO Preparazione all’avviamento Regolazione servomotore 1 - 4 : Camma di fine corsa (max apertura serranda aria) : Camma di fine corsa (chiusura serranda aria) 3 - 5 : Camma di posizione portata minima (e di accensione) : Indice di lettura posizionamento : Sblocco servomotore Il servomotore regola contemporaneamente, tramite rinvii, portata e...
Page 18
All manuals and user guides at all-guidesbox.com CAPITOLO Preparazione all’avviamento Procedura per la taratura del bruciatore • Portare il commutatore AUTO / MAN, posto sul pannello di controllo, nella posizione MAN (manuale). • Accendere il bruciatore. Se l’accensione non avviene può essere che il gas non arrivi alla testa di combustione entro il tempo di sicurezza di 3 s. Aumentare allora la portata di gas all’accensione.
All manuals and user guides at all-guidesbox.com CAPITOLO Preparazione all’avviamento Taratura dei pressostati Pressostato aria Eseguire la regolazione del pressostato aria dopo aver effettuato tutte le altre regolazioni del bruciatore con il pressostato aria regolato a inizio scala (Fig. 23). Con il bruciatore funzionante alla potenza MAX aumentare la pressione di regolazione girando lentamente in senso orario l'apposita manopolina fino al blocco del bruciatore.
All manuals and user guides at all-guidesbox.com CAPITOLO Preparazione all’avviamento Controllo presenza fiamma La corrente minima per un corretto funzionamento è di 70 µA. Se il valore è inferiore può dipendere da: • cellula esaurita; • tensione bassa (inferiore a 187 V); •...
All manuals and user guides at all-guidesbox.com Manutenzione Problemi e procedure di risoluzione Quando si verifica un malfunzionamento del bruciatore occorre prima di tutto: controllare che i collegamenti elettrici siano stati eseguiti correttamente; accertarsi che vi sia la disponibilità della portata di combustibili; controllare che tutti i parametri di regolazione (per es.
Page 22
All manuals and user guides at all-guidesbox.com CAPITOLO Manutenzione Inconveniente Causa probabile Rimedio consigliato Il bruciatore continua a ripetere il • La pressione del gas in rete è vicina al valore ..Ridurre la pressione d’intervento del ciclo di avviamento senza sul quale è...
Page 23
All manuals and user guides at all-guidesbox.com General warnings Informations about the This handbook is a supplement to the burner and must always be kept handbook with it. It should be read carefully as it supplies important information for installation, use and maintenance; it should be kept in a safe place for future consultation.
Page 24
All manuals and user guides at all-guidesbox.com Index CHAPTER Introduction ..... page 3 Selection code description ..... . 3 Specification of the burner type and coding .
Page 25
All manuals and user guides at all-guidesbox.com Introduction Selection code description Specification of the burner type and coding TYPE CODE DB 6 TC A-0 DB 4 SM CO1 TC 20080068 Combustive air DB 6 SM CO1 TC 20075270 supply A-0 = from below A-90 = from the right A-180 = from above A-270 = from the left...
Page 26
All manuals and user guides at all-guidesbox.com Burner description Technical data Model DB 4 SM CO1 A0 DB 6 SM CO1 A0 Type 80068X 75270X Capacity Min./Max. natural gas [kW] 1200/3000 ÷ 5000 1400 ÷ 7800 Output adjustment Modulante Fuel Natural gas (G 20) - Net calorific value 10 kWh/Nm Natural gas (G 25) - Net calorific value 8.6 kWh/Nm Combustive air temperature...
Page 27
All manuals and user guides at all-guidesbox.com CHAPTER Burner description Burner components 20076243 Fig. 2 14 Gas connection flange 15 Shutter Air box Cover 16 Lever for moving combustion head Servomotor 17 Air damper command lever Control box base for electrical connections 18 Gas butterfly valve command lever Boiler attachment flange 19 Variable profile cam...
Page 28
All manuals and user guides at all-guidesbox.com CHAPTER Burner description Overall dimensions 20076244 Fig. 3 DB 4 1550 1024 ø 312 DB 6 1518 1024 ø 363 FLANGE DIMENSIONS DB4 SM Air duct connection Fixing to the boiler Gas supply 3 5 0 6 5 , 5 D7549...
Page 29
All manuals and user guides at all-guidesbox.com CHAPTER Burner description FLANGE DIMENSIONS DB6 SM Air duct connection Fixing to the boiler Gas supply 3 8 0 1 6 0 D7549 4 9 5 DN 80 D8325 D3974 Fig. 8 Fig. 9 Fig.
Page 30
All manuals and user guides at all-guidesbox.com CHAPTER Burner description Air side pressure drop (taken upstream from the completely open air damper) D12215 3000 4000 5000 6000 7000 8000 Burner output Pb [kW] Fig. 10 The pressure curves refer to the different adjustment conditions for the combustion head in accordance to the graphic on page 13. Refer to Paragraph 5.1.
Page 31
All manuals and user guides at all-guidesbox.com CHAPTER Burner description Gas side pressure drop Gas pressure on the basis of Head pressure drop D7541 the maximum output developed by the burner is given by the curves in Fig. 11. It represents the pressure drop in the combustion head.
Page 32
All manuals and user guides at all-guidesbox.com Installation Removal of the locking screws from the shutter Remove the screws and the nuts 1) and 2)(Fig. 13), before installing the burner on the boiler. Replace them with the screws 3) M12x16 supplied with the burner.
Page 33
All manuals and user guides at all-guidesbox.com Fuel supply General gas supply layout (example) D7543 max. 500 mbar 0.5 ÷ 4 bar Fig. 16 Anti-vibration joint PGm Minimum gas pressure switch Gas filter Gas butterfly valve HPG High gas pressure regulator Pressure limiting valve with outlet into the environment Low gas pressure regulator Pressure gauge...
Page 34
All manuals and user guides at all-guidesbox.com CHAPTER Fuel supply Wiring diagrams D9854 Fig. 17 Burner terminal strip Air pressure switch PGM Maximum gas pressure switch Servomotor UV Cell Ignition transformer Burner earth...
Page 35
All manuals and user guides at all-guidesbox.com Preparation for start up Combustion head setting Loosen the screw 1) and turn the graduated sector 2) according dia- grams Fig. 19. The system allows an optimal setting even at a minimum firing rate. Combustion head opening can be varied by moving the lever onto holes from 0 to 6, Fig.
Page 36
All manuals and user guides at all-guidesbox.com CHAPTER Preparation for start up Position of electrodes Make sure that the electrode and the probe are positioned as shown in Fig. 20. 20076847 Fig. 20...
Page 37
All manuals and user guides at all-guidesbox.com CHAPTER Preparation for start up Servomotor adjustment 1 - 4 : Limit switch cam (max. air damper opening) : Limit switch cam (air damper closed) 3 - 5 : Minimum delivery (and ignition) position cam : Positioning reading indicator : Servomotor release The servomotor contemporarily regulates, by transmission, air delivery...
Page 38
All manuals and user guides at all-guidesbox.com CHAPTER Preparation for start up Procedures for setting the burner • Turn the AUTO / MAN selection switch on the control panel to MAN (manual). • Turn the burner on. If it does not ignite, it could mean that the gas does not reach the combustion head within the safety time period of 3 s. In this case increase the ignition gas delivery level.
Page 39
All manuals and user guides at all-guidesbox.com CHAPTER Preparation for start up Pressure switches setting Air pressure switch Adjust the air pressure switch after having performed all other burner adjustments with the air pressure switch set to the start of the scale (Fig. 23). With the burner operating at max.
Page 40
All manuals and user guides at all-guidesbox.com CHAPTER Preparation for start up Flame present check Minimum current for correct working is 70 µA. If the value is lower, it could be due to: • exhausted photocell; • low current (lower than 187 V); •...
Page 41
All manuals and user guides at all-guidesbox.com Maintenance Problems and remedies If the burner does not work properly, first you must: check that the electric connections have been correctly performed; ensure that the fuel is delivered correctly; check that all the adjustment parameters (e.g. boiler water temperature or boiler steam pressure) are correctly set. In the event of a burner lockout, more than two consecutive burner reset operations could cause damage to the installation.
Page 42
All manuals and user guides at all-guidesbox.com CHAPTER Maintenance Fault Possible cause Recommended remedy The burner repeats the starting • Mains gas pressure is near the value to which ..Reduce operating pressure cycle without lock out the min.
Page 43
All manuals and user guides at all-guidesbox.com 一般提示 关于本手册 本手册随燃烧器附带提供并且不允许与燃烧器分离,安装、使 用和维护燃烧器前须认真阅读,并妥善保管以备查阅。 手册使用者 本手册给具有燃油及燃气燃烧器工作经验的有关人员提供。 本手册包括下列相关信息: - 安装; - 使用; - 维护; - 安全注意事项。 本手册的使用人员必须具有操作这类燃烧器的资质及丰富的现 场工作经验。 相关文件 - 燃气阀组 - 控制面板接线图 - 出力调节器 ( 比例调节 )
Page 44
All manuals and user guides at all-guidesbox.com 目录 第 章简介 ... . 页码 命名规则说明 ......3 燃烧器型号及编码.
All manuals and user guides at all-guidesbox.com 简介 命名规则说明 燃烧器型号及编码 型号 编码 DB 6 TC A-0 DB 4 SM CO1 TC 20080068 DB 6 SM CO1 TC 20075270 助燃空气供应方向 A-0 = 从底部 A-90 = 从右侧 A-180 = 从上部 A-270 = 从左侧 燃烧头...
Page 61
All manuals and user guides at all-guidesbox.com 维护 故障及其解决方案 如果燃烧器不能正常工作,首先要做如下检查: 检查电气连接是否正确; 确保燃料输送正确; 检查所有调整参数 ( 如锅炉内水温或锅炉压力 ) 设置是否正确。 在燃烧器锁定的情况下,连续进行两次以上燃烧器复位操作会导致设备损坏。 第三次锁定时,请联系售后服务部门。 如果出现更多锁定或燃烧器故障,只能由具备相应资格且经过授权的人员来维修,并且要遵循本手册的指示和遵守 警告 现行的法律法规。 建议解决方案 故障 可能的原因 燃烧器不能启动 • 无电源 ....闭合所有开关 - 检查电气连接 •...
Page 62
All manuals and user guides at all-guidesbox.com 第 章 维护 建议解决方案 故障 可能的原因 燃烧器反复重新启动不锁定 供气管道中燃气压力非常接近于最低燃气 ..减少最低燃气压力开关设置值 压力开关的设置值。在阀门打开后的压力 或更换燃气过滤器。 突然减小导致压力开关断开,阀门立即关 闭,燃烧器停机。压力再次提高,压力开 关再次闭合,并且重复进行点火周期。 • 压力开关故障 ....更换 运行期间锁定停机...
Page 63
All manuals and user guides at all-guidesbox.com...
Page 64
All manuals and user guides at all-guidesbox.com RIELLO S.p.A. I-37045 Legnago (VR) Tel.: +39.0442.630111 http:// www.riello.it http:// www.rielloburners.com Con riserva di modifiche - Subject to modifications - 修订版...
